【ZS二位二通微型系列直動式電磁閥（常閉型）】-上海浦蝶閥門有限公司
二位二通常閉型電磁閥,斷電關閉,通電打開;產品為系列化生產,體積小,流量大,適用范圍廣 閥體材質為:銅,SS304不銹鋼,SS316不銹鋼(定) 環境溫度: 0℃～65℃ 介質溫度: 0℃～120℃ 安裝:按閥上所標流向箭頭,可任意安裝;為增強使用壽命,最好線圈向上,水平安裝. 電壓:AC24V/110V/220V/230V/240V 50/60HZ DC24V/12V ±10%允許波動.可選配德國NASS線圈 密封件:可采用NBR、VITON、EPDM等多種,以適應不同流體的開關控制.
 型號規格
| 接管口徑 | 流量通徑mm | CV值 | 壓力差（Kgf/cm2) | 最大溫度℃ | 線圈配置 | 功率 | 線圈等級 | 訂貨型號規格以下表中
型號規格電壓是220VAC | 重量KG | | 最小壓力 | 最大工作壓力 | VA | W | | 空氣瓦斯 | 水、熱水液體 | 輕油≤20CST | AC220V | DC24V | 閥體材料 | | AC | DC | AC | DC | AC | DC | 鍛銅 | 不銹鋼SS304 | 1/8” 只配
N05型線圈 | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | 7 | 5 | 80 | N | 13 | 8.5 | B | ZS1NF02N1AC3 | ZS1NF02N4AC3 | 0.35 | | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | | | 120 | N | 13 | 8.5 | B | ZS1NF02E1AC3 | ZS1NF02E4AC3 | 0.35 | | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | 7 | 5 | 120 | N | 13 | 8.5 | B | ZS1NF02V1AC3 | ZS1NF02V4AC3 | 0.35 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 80 | N | 13 | 8.5 | B | ZS1NF02N1AC3 | ZS1NF02N4AC3 | 0.35 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | | | 120 | N | 13 | 8.5 | B | ZS1NF02E1AC3 | ZS1NF02E4AC3 | 0.35 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 120 | N | 13 | 8.5 | B | ZS1NF02V1AC3 | ZS1NF02V4AC3 | 0.35 | | 1/8” | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 80 | D | 33 | 20 | F | ZS1DF02N1A05 | ZS1DF02N4A05 | 0.46 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | | | 120 | D | 33 | 20 | F | ZS1DF02E1A05 | ZS1DF02E4A05 | 0.46 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 120 | D | 33 | 20 | F | ZS1DF02V1A05 | ZS1DF02V4A05 | 0.46 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 80 | D | 33 | 20 | F | ZS1DF02N1A06 | ZS1DF02N4A06 | 0.46 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | | | 120 | D | 33 | 20 | F | ZS1DF02E1A06 | ZS1DF02E4A06 | 0.46 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 120 | D | 33 | 20 | F | ZS1DF02V1A06 | ZS1DF02V4A06 | 0.46 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 80 | D | 33 | 20 | F | ZS1DF02N1AC8 | ZS1DF02N4AC8 | 0.45 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | | | 120 | D | 33 | 20 | F | ZS1DF02E1AC8 | ZS1DF02E4AC8 | 0.45 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 120 | D | 33 | 20 | F | ZS1DF02V1AC8 | ZS1DF02V4AC8 | 0.45 | 1/4”
只配
N05型線圈 | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | 7 | 5 | 80 | N | 13 | 20 | B | ZS1NF02N1BC3 | ZS1NF02N4BC3 | 0.34 | | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | | | 120 | N | 13 | 8.5 | B | ZS1NF02E1BC3 | ZS1NF02E4BC3 | 0.34 | | 2.5 | 0.23 | 0 | 7 | 5 | 7 | 5 | 7 | 5 | 120 | N | 13 | 8.5 | B | ZS1NF02V1BC3 | ZS1NF02V4BC3 | 0.34 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 80 | N | 13 | 8.5 | B | ZS1NF02N1BC3 | ZS1NF02N4BC3 | 0.34 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | | | 120 | N | 13 | 8.5 | B | ZS1NF02E1BC3 | ZS1NF02E4BC3 | 0.34 | | 3 | 0.3 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 120 | N | 13 | 8.5 | B | ZS1NF02V1BC3 | ZS1NF02V4BC3 | 0.34 | | 1/4” | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 80 | D | 33 | 8.5 | F | ZS1DF02N1B05 | ZS1DF02N4B05 | 0.45 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | | | 120 | D | 33 | 20 | F | ZS1DF02E1B05 | ZS1DF02E4B05 | 0.45 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 120 | D | 33 | 20 | F | ZS1DF02V1B05 | ZS1DF02V4B05 | 0.45 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 80 | D | 33 | 20 | F | ZS1DF02N1B06 | ZS1DF02N4B06 | 0.45 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | | | 120 | D | 33 | 20 | F | ZS1DF02E1B06 | ZS1DF02E4B06 | 0.45 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 120 | D | 33 | 20 | F | ZS1DF02V1B06 | ZS1DF02V4B06 | 0.45 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 80 | D | 33 | 20 | F | ZS1DF02N1BC8 | ZS1DF02N4BC8 | 0.44 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | | | 120 | D | 33 | 20 | F | ZS1DF02E1BC8 | ZS1DF02E4BC8 | 0.44 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 120 | D | 33 | 20 | F | ZS1DF02V1BC8 | ZS1DF02V4BC8 | 0.44 |
ZS二位二通微型系列直動式電磁閥〈常閉型〉 型號規格 , , | 接管口徑 | 流量通徑mm | CV值 | 壓力差（Kgf/cm2) | 最大溫度℃ | 線圈配置 | 功率 | 線圈等級 | 訂貨型號規格以下表中
型號規格電壓是220VAC | 重量KG | | 最小壓力 | 最大工作壓力 | VA | W | | 空氣瓦斯 | 水、熱水液體 | 輕油≤20CST | AC220V | DC24V | 閥體材料 | | AC | DC | AC | DC | AC | DC | 鍛銅 | 不銹鋼SS304 | | 3/8” | 4 | 0.6 | 0 | 8 | 5 | 8 | 5 | 5 | 5 | 80 | D | 33 | 20 | F | ZS1DF02N1C04 | ZS1DF02N4C04 | 0.6 | | 4 | 0.6 | 0 | 8 | 5 | 8 | 5 | | | 120 | D | 33 | 20 | F | ZS1DF02E1C04 | ZS1DF02E4C04 | 0.6 | | 4 | 0.6 | 0 | 8 | 5 | 8 | 5 | 5 | 5 | 120 | D | 33 | 20 | F | ZS1DF02V1C04 | ZS1DF02V4C04 | 0.6 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 80 | D | 33 | 20 | F | ZS1DF02N1C05 | ZS1DF02N4C05 | 0.51 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | | | 120 | D | 33 | 20 | F | ZS1DF02E1C05 | ZS1DF02E4C05 | 0.51 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 120 | D | 33 | 20 | F | ZS1DF02V1C05 | ZS1DF02V4C05 | 0.51 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 80 | D | 33 | 20 | F | ZS1DF02N1C06 | ZS1DF02N4C06 | 0.51 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | | | 120 | D | 33 | 20 | F | ZS1DF02E1C06 | ZS1DF02E4C06 | 0.51 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 120 | D | 33 | 20 | F | ZS1DF02V1C06 | ZS1DF02V4C06 | 0.51 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 80 | D | 33 | 20 | F | ZS1DF02N1CC8 | ZS1DF02N4CC8 | 0.49 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | | | 120 | D | 33 | 20 | F | ZS1DF02E1CC8 | ZS1DF02E4CC8 | 0.49 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 120 | D | 33 | 20 | F | ZS1DF02V1CC8 | ZS1DF02V4CC8 | 0.49 | | 10 | 1.6 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | 0.4 | 0.2 | 80 | D | 33 | 20 | F | ZS1DF02N1C10 | | 0.62 | | 10 | 1.6 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | | | 120 | D | 33 | 20 | F | ZS1DF02E1C10 | 0.62 | | 10 | 1.6 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | 0.4 | 0.2 | 120 | D | 33 | 20 | F | ZS1DF02V1C10 | 0.62 | | 1/2” | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 80 | D | 33 | 20 | F | ZS1DF02N1D05 | ZS1DF02N4D05 | 0.48 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | | | 120 | D | 33 | 20 | F | ZS1DF02E1D05 | ZS1DF02E4D05 | 0.48 | | 5 | 0.65 | 0 | 6 | 4 | 6 | 4 | 4 | 3 | 120 | D | 33 | 20 | F | ZS1DF02V1D05 | ZS1DF02V4D05 | 0.48 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 80 | D | 33 | 20 | F | ZS1DF02N1D06 | ZS1DF02N4D06 | 0.48 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | | | 120 | D | 33 | 20 | F | ZS1DF02E1D06 | ZS1DF02E4D06 | 0.48 | | 6 | 0.8 | 0 | 4 | 2.5 | 4 | 2.5 | 3 | 2.5 | 120 | D | 33 | 20 | F | ZS1DF02V1D06 | ZS1DF02V4D06 | 0.48 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 80 | D | 33 | 20 | F | ZS1DF02N1DC8 | ZS1DF02N4DC8 | 0.46 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | | | 120 | D | 33 | 20 | F | ZS1DF02E1DC8 | ZS1DF02E4DC8 | 0.46 | | 7.5 | 1.0 | 0 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 120 | D | 33 | 20 | F | ZS1DF02V1DC8 | ZS1DF02V4DC8 | 0.46 | | 10 | 1.65 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | 0.4 | 0.2 | 80 | D | 33 | 20 | F | ZS1DF02N1D10 | | 0.59 | | 10 | 1.65 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | | | 120 | D | 33 | 20 | F | ZS1DF02E1D10 | | 10 | 1.65 | 0 | 0.5 | 0.3 | 0.5 | 0.3 | 0.4 | 0.2 | 120 | D | 33 | 20 | F | ZS1DF02V1D10 |
